–3–
REV. F
AD8009
SPECIFICATIONS
(@ T
A
= 25C, V
S
= 5 V, R
L
= 100 , for R Package: R
F
= 301 for G = +1, +2,
R
F
= 200 for G = +10).
AD8009AR/JRT
Model Conditions Min Typ Max Unit
DYNAMIC PERFORMANCE
–3 dB Small Signal Bandwidth, V
O
= 0.2 V p-p
G = +1, R
F
= 301 Ω 630 MHz
G = +2 430 MHz
G = +10 300 MHz
Large Signal Bandwidth, V
O
= 2 V p-p G = +2 365 MHz
G = +10 250 MHz
Gain Flatness 0.1 dB, V
O
= 0.2 V p-p G = +2, R
L
= 150 Ω 65 MHz
Slew Rate G = +2, R
L
= 150 Ω, 4 V Step 2,100 V/µs
Settling Time to 0.1% G = +2, R
L
= 150 Ω, 2 V Step 10 ns
G = +10, 2 V Step 25 ns
Rise and Fall Time G = +2, R
L
= 150 Ω, 4 V Step 0.725 ns
HARMONIC/NOISE PERFORMANCE
Second Harmonic G = +2, V
O
= 2 V p-p 10 MHz –74 dBc
20 MHz –67 dBc
70 MHz –48 dBc
Third Harmonic 10 MHz –76 dBc
20 MHz –72 dBc
70 MHz –44 dBc
Input Voltage Noise f = 10 MHz 1.9 nV/√Hz
Input Current Noise f = 10 MHz, +In 46 pA/√Hz
f = 10 MHz, –In 41 pA/√Hz
DC PERFORMANCE
Input Offset Voltage 14 mV
–Input Bias Current 50 150 ±µA
+Input Bias Voltage 50 150 ±µA
INPUT CHARACTERISTICS
Input Resistance +Input 110 kΩ
–Input 8 Ω
Input Capacitance +Input 2.6 pF
Input Common-Mode Voltage Range 1.2 to 3.8 V
Common-Mode Rejection Ratio V
CM
= 1.5 V to 3.5 V 50 52 dB
OUTPUT CHARACTERISTICS
Output Voltage Swing 1.1 to 3.9 V
Output Current R
L
= 10 Ω, P
D
Package = 0.7 W 175 mA
Short-Circuit Current 330 mA
POWER SUPPLY
Operating Range +5 ±6V
Quiescent Current 10 12 mA
Power Supply Rejection Ratio V
S
= 4.5 V to 5.5 V 64 70 dB
Specifications subject to change without notice.
