1. General description
The 74HC04-Q100; 74HCT04-Q100 is a hex inverter. Inputs also include clamp diodes,
this enables the use of current limiting resistors to interface inputs to voltages in excess of
V
CC
.
This product has been qualified to the Automotive Electronics Council (AEC) standard
Q100 (Grade 1) and is suitable for use in automotive applications.
2. Features and benefits
Automotive product qualification in accordance with AEC-Q100 (Grade 1)
Specified from 40 C to +85 C and from 40 C to +125 C
Complies with JEDEC standard JESD7A
Complies with JEDEC standard JESD8-1A
Input levels:
For 74HC04-Q100: CMOS level
For 74HCT04-Q100: TTL level
ESD protection:
MIL-STD-883, method 3015 exceeds 2000 V
HBM JESD22-A114F exceeds 2000 V
MM JESD22-A115-A exceeds 200 V (C = 200 pF, R = 0 )
Multiple package options
74HC04-Q100; 74HCT04-Q100
Hex inverter
Rev. 2 — 10 April 2013 Product data sheet
